Crest for Mac Pro SSD
internal SATA 3 6Gb/s
professional class SSD for your Mac Pro
with native Mac TRIM support
configure
Overview
Upgrade your Mac Pro
The Crest for Mac Pro SSD is the most easy solution to upgrade your Mac Pro desktop to ultrafast Solid State Drive to squeeze the most out of your Apple computer.
Amazingly Easy
Hassle free installation straight from the box. It’s ready to work for you and no technical know-how required. Finally you can upgrade your Mac Pro Desktop in seconds to SSD at an affordable price. Simply open your Mac Pro, mount it on an existing Drive Bay and plug it in, it really is that simple!.
Work faster, play harder
Crest for Mac Pro SSD is the unique all in one solution for your Apple Mac Pro. Benefit from the reliability and quality of Angelbird Crest for Mac Pro SSD. Gain maximum performance with SSDs. You will never want to look back.
TRIM enabled
Supports TRIM on your Mac out of the box.
What is TRIM?
SSDs are faster than traditional hard disk drives, but they can't keep up their quick speed forever. In order to maintain an SSD, you need the TRIM command, a garbage collection utility that is built in to the background of your Operating System. Crest for Mac SSD is the only 3rd party SSD that supports TRIM for Mac straight from the box. No driver, software or TRIM Enabler is needed!
Reliable
To safely store your data, Crest for Mac Pro SSD comes with overload power protection, power loss protection (UPS) and a 3 year warranty.
Main Features
- Designed for Mac Pro.
- Built in Uninterruptible Power Supply. This ensures your drive the highest level of protection.
- Special designed power circuit to protect from overloading and static shocks.
- Optimized design for low latency and super high signal integrity.
- Designed for use in an extended temperature range. This ensures longer live in harsh temperature conditions.
Technical Specifications
General Specifications
| Compatibility | Mac Pro 3.1 and later. |
|---|---|
| Mac TRIM support | Out of the box. |
| Capacity | 120GB, 240GB, 480GB |
| Interface | SATA 6Gb/s, 3Gb/s and 1.5Gb/s supported. SATA 3.0 Compliant |
| Controller | SandForce® SF-2281 Series |
| Over provisioning | ~7% |
| Flash | Grade A Intel® or Micron® Asynchronous MLC |
| Form factor | Mac Pro Drive Bay |
| Features | In-drive UPS, Overload protection, TCG OPAL, Auto-TRIM, ECC, RAISE, EMS protection, Builtin cache, SMART |
| Casing material | Aluminium |
Performance Specifications
| Sustained Read speed1 | up to 560MB/s |
|---|---|
| Sustained Write speed1 | up to 530MB/s |
| IOPS2 | Up to 85000 |
| Access Time | < 0.1ms |
Acoustic Specifications
| Noise (idle) | 0.0db |
|---|---|
| Noise (load) | 0.0db |
| Vibration | 0 Hz |
Reliability Specifications
| Warranty | 3 years |
|---|---|
| MTBF | > 2,000,000 hours |
| Data Reliability | Built-in EDC/ECC function |
| Data Retention | 10 years at 25°C |
| ECC | 16 bits per 512 bytes |
| Certifications | RoHS 6/6, FCC, CE |
Environmental Specifications
| Shock (operating) | 2000G |
|---|---|
| Vibration (operating) | 20G |
| Operating Temp. | 0°C ~ +70°C |
| Storage Temp. | -40°C ~ 85°C |
| Operating Humidity | 5% to 95% non-condensing |
Electrical Specifications
| DC input voltage | 5V ± 5% |
|---|---|
| Power usage (idle) | 0.5w |
| Power usage (max) | 3.0W |
Physical Dimensions
| Width | 105mm ± 0.2mm |
|---|---|
| Height | 15mm ± 0.2mm |
| Lenght | 100.2mm ± 0.2mm |
| Weight | 135g |
1 Tested with ATTO Benchmark Tool v2.46.
2 Disk aligned / 4KB random write / QD 30
